Nedis USB 2.0 Type C Adaptor Male to Micro Usb B Female 233-0649

Antenna V Zenit 5G LTE 149221 12-00-0024

The Televes 149221 '' V '' ZENIT 5G LTE UHF antenna, for receiving channels from 21 to 48, has a V-type construction, with a 10-element dihedral reflector and 2 Yagi stems, providing excellent performance, in compact dimensions. The data design offers cut-off of 5G mobile phone frequencies, above channel 48, without loss in the reception curve of the desired frequencies of the transit band (channels 21 up to 48). It is made of high density aluminum alloy for corrosion protection and long life as well as ABS plastic, weather resistant. The web connector is made of Zamak alloy for stability and robustness, even in areas with adverse weather conditions, while the built-in junction box is shielded to prevent pulsed noise in the Terrestrial Digital Signal.

Specifications:
- With 10-element dihedral reflector.
- With shielded integrated box, to avoid pulsed noise on the Terrestrial Digital Signal.
- Band: UHF, channels 21 ... 48, Mhz: 470 ... 698
- Yield: dBi 13
- Front-to-Back ratio: dB> 23
- Wind load: N / m2: 93 (@ 130 Km / h), 128 (@ 150 Km / h)
- Tissue diameter: 20 ... 50 mm.
