Mast Amplifier with 24V with PSU 568002 Nano Kom 12-11-0006

Edision Satelite Converter LNB TL-2 Double for 1 Satelite LNB TL-2 TWIN 03-01-0009

Specifications:
- Low band input: 10.7 ... 11.70 GHz
- High band input: 11.7 ... 12.75 GHz
- Low band output: 950 ... 1950 MHz
- High band output: 1100 ... 2150MHz
- Yield: 55dB (minimum)
- Noise Figure (dB) Low band: 0.5 dB (standard), high band: 0.5 dB (standard) 6dB (maximum)
- Output plug: type F, 75Ω female
- Output return losses: -10dB (maximum, at temperature 25C / 77F)
- L.O. low band frequency: 9.75 GHz, high band: 10.6GHz
- L.O. frequency stability ± 1MHz (maximum at 25C / 77F)
- DC Consumption: 130mA (maximum)
- Operating voltage: Vertical: 10 ... 14 Vdc, Horizontal: 15.5 ... 21 Vdc
- Band Switch: Low Band: 0 Hz, High Band: 22 KHz ± 4KHz
- Operating environment temperature: -40C ... + 60C
- Storage environment temperature: -55C ... + 80C
- Warranty: 2 years
