Differential Thermal Detector BS-660/EX Explosion Type 980166002

External Beam Detector 100m ABT-100 980600100

BEAM range up to 100m photoelectric.

Manufacturer Code: 980600100

Specifications

ABT-40 (Black Series) Pair of Active Infrared Beam Detectors 40 meters
ABT-40 double beam infrared beam pair (2 light beams). It is waterproof and can operate up to 40 meters outdoors or up to 120 meters indoors. It has Alarm NO & NC contacts as well as protection Tamper.
It has indicator lights of good operation (GOOD), alarm (ALARM) as well as indicator of the level of the beam (LEVEL) which shows us depending on its brightness the accuracy of the light beam between transmitter and receiver.
It has a response time slider, to achieve the best possible response of the detector depending on the conditions of the installation. It allows you to easily adjust the inclination of the infrared beams by 20º (± 10º from the horizontal axis) as well as the possibility of complete rotation inside the housing by 180º (± 90º).
 Number of Beams: 2 Beams
 Response Time: 50-700ms
 Alarm Contacts: NO & NC, 30V 0.5A max.
 Power supply: AC: 12-18V or DC: 12-24V
 Consumption: <85mA (Pair)
 Operating temperature: -25 ~ 55ºC
 Protection Tamper: NAI (contact NO, AC / DC 30V 0.5A max)
 Horizontal Lens Rotation: 180º (± 90º)
 Vertical lens rotation: 20º (± 10º)
 Net Weight: 535gr (Pair)
 Gross Weight: 740gr (Pair)
