Adaptor for Watertight Junction Box Φ16 Black Durosol Plus 4051016

Heavy Τype Βend Φ32 Black Durosol Plus 4053032

DUROSOL PLUS Bend is part of halogen free  DUROSOL PLUS – DUROFLEX PLUS conduit system for cable management and protection. Along with the 3layer rigid DUROSOL PLUS, 3layer pliable conduit DUROFLEX PLUS, the fittings connection coupler, clip, adaptor and the juction boxes with seals, all in black color RAL 9004, compose a unique conduit system capable of meeting a plethora of needs at the installation field.

APPLICATION STANDARD:EN 61386.21, ΕΝ 50642, ΕΝ 60754-2

INSTRUCTIONS FOR COMPLIANCE:2014/35/EE (LVD), 2011/65/EE (RoHS)

COLOR:RAL 9004 Μαύρο

NOMINAL DIAMETER:Βάση εξωτερικής διαμέτρου (DN/OD)

PROPERTIES

1) No toxic or corrosive gases in case of fire

2) High ingress protection (min IP65), when connected with DUROSOL PLUS coupler

3) Marked using embossed printing and packed in 100% recyclable packaging for their maximum protection

4) Not attractive to rodents

5) UV stabilized

6) Incorporates antistatic technology which protects against static electricity (Patent Protected: 1009810)

7) Protection against scratching from cable routing (Patent Protected: 1010513)

Properties

Resistance to impact: 6J (at -25oC)

Lower temperature range: -25oC

Upper temperature range: +120oC

Electrical characteristics: With electrical insulated characteristics

Protection against ingress of solid objects: min IP65

Protection against ingress of water: min IP65

Resistance to flame propagating: Non flame propagating

Antiscratch Technology: Protection against scratching from cable routing

Additional properties

Raw material: Halogen free, heavy metals free (RoHS) and specially stabilized thermoplastic PC blend

Ageing resistance: UV stabilized

Halogen free: No toxic or corrosive gases in case of fire

Rodent repellent: Not attractive to rodents

Antistatic technology: Protection against static electricity
